Part Name:
PTO DESCRIPTION:
1. Series 4
2. 30in. collapsed length, measured from end to end of the PTO shaft
3. 44in. Maximum extended working length, measured from end to end of the PTO shaft
4. Quick-disconnect 1 3/8in.-6 spline x 1 3/8in. round bore
5. 35 HP max. Rating

SPECIFICATION:
Product Length 30 Inches
Product Width 5 Inches
Product Height 5 Inches
Package Size 6" x6" x 30"
Steel Tube 16Mn Drive shaft material 45 # Forged Pieces
Undershelf Capacity 19 lb.

series4, 30a€ minimun overall length 1-3/8 in./6 spline tractor yoke, 1-3/8 in. round pin implement yoke

NOTE: Complete driveline is economical and easy to install, so you don't have to spend time trying to repair damaged or worn shafts. Can be cut to desired length to meet your driveline needs. Meets all ASAE standards.
